BRE2200 Rectangular Static Bar

BRE2200 Rectangular Static Bar

Contact and separation between two surfaces creates static electricity, which can often cause materials like paper, plastic, textiles and other non-conductive materials to randomly attract to or repel from themselves or their surroundings.

Because some of our products are made in various sizes, part numbers and pricing will vary. Please contact us at techsales@staticclean.com or click the “Request a Quote” button below. We look forward to serving your static control and/or contamination control needs.

SKU: BR22006.00A06AS Categories: , , ,

Description

The BRE2200 Rectangular Static Bar is a “shockless” linear air ionizer that generates a dense field of positive & negatively charged air ions. Exposing materials to this field efficiently neutralizes electrostatic charges that can cause a myriad of costly process, quality or safety issues; material jams, clogs, mis-feeds, poor stacking, reduced transport speeds, shock to operators, fires, explosions and a variety of ESA (electrostatic attraction) contamination related issues to name a few.

View the International Nonwoven Disposables Association’s Mission and Goals for 2021

Additional information

Weight 1.1 lbs
Dimensions 8 × 8 × 8 in
Size

6", 12", 18", 24"

Features & Benefits

  • Small profile for installation in tight spaces
  • Available in lengths up to 12 feet
  • Versatile, adjustable mounting hardware for ease of installation
  • Enlarged air-dielectric cavity at end cap dramatically improves reliability
  • Capacitively coupled 316 stainless steel emitter pins for shockless operation
  • Integral 72″ High Voltage cable in a flex conduit
  • Spring-loaded connector kit fits many 7.0~8.0kv power supplies

Technical Data

  • Outer Bar: 0.75″W x 0.88″H Clear Anodized Aluminum Extrusion
  • Overall Length: 4.75″ to 142.75″ in 3″ increments (custom sizes available)
  • Effective Length: 1.06″ less than overall length
  • Optimum Range: 0.75″ to 3″ from target
  • Emitters: 316 Stainless Steel spaced ¾” on-center
  • Mounting: Universal Brackets with adjustable 8-32 x 0.5″ studs & hex-nuts (included)
  • Certification: UL, cUL, CE High Voltage
  • Cable: 72″ High Voltage Cable in Flex Conduit, with factory installed spring-loaded connector to mate with a TSN70, TSN75A, or comparable 7.0kV ~ 8.0kV power supply (sold separately). Optional shielded HV cable available
